Life Sciences

Thermal Cycler

CycleReady CR 96 is a key piece of equipment for molecular biologyresearch. lt utilizes thermal cycling technology to accurately control the temperature so thatspecific gene fragments can be rapidly amplified. With stable performance and convenientoperation, it is widely used in scientific research, medical treatment, testing and other fieldsproviding efficient and reliable technical means for gene analysis and disease diagnosis.

Consultation

Features

Power failure protection: automatically execute the remaining unfinished part of the program after power supply is restored.

Stable temperature control:industrial-grade hot spot semiconductor precise temperature control,excellentinter-hole uniformity.

Wide gradient range of 36℃,greatly facilitating annealing temperature research.

Lightweight design, small volume, light weight suitable for a variety of complex experimental environments

Unique rear air outlet design, no heat dissipation pressure for multiple machines side by side.

Specifications

Model
CycleReady CR 96
Sample volume and consumable type
96-well×0.2 mL (Full-skirted plate,half-skirted plate,Non-skirted plate; 12×8 strip tubes,8×12 strip tubes,Single tube)
Technology program
Thermoelectric semiconductor technology
Screen adjustability
Fixed
Block temperature range
4~105°C
Maximum ramp rate
5℃/s
Temperature uniformity
±0.2℃ (55℃）
Temperature accuracy
≤ ±0.1℃(55℃)
Gradient
1℃-36℃ ; accuracy is ±0.5℃
Temperature control mode
Block mode, Tube mode
Ramp rate adjusting range
0.1~5℃
Program capacity
Infinite
Hot lid temperature accuracy
0.1℃
Monitor
7-inch Color touch screen
Smart Heat Lid
The thermal cover closes automatically if the sample stage is cryogenically preserved or at the end of the program.
Input power
100~240VAC.50/60Hz
